Quality Control & Management

Yes. Digital calipers, scales and measurement devices can send values directly to avoid typing errors.

AI Computer Vision performs automatic visual inspections and its results flow into the same quality records and SPC charts.

Incoming inspection results build automatic supplier quality ratings used by SCP.

No. Control plans, in-process inspections and non-conformities run entirely on operator and inspector entry at the workstation. Machine and gauge connections change what the record is worth rather than whether it exists: a measurement stamped with the machine, shift and lot it came from is traceable without anyone having to remember. Gauge capture also needs a gauge with a data output and an interface at the station, so it applies to some characteristics and not others. Connect the characteristics that matter first.

Three things, none of them software. The characteristic has to be measured with a measurement system whose repeatability and reproducibility are small against both the tolerance and the process variation, with enough resolution to see the spread being charted, or the chart plots measurement noise. Samples have to be taken as rational subgroups, from the same setup and consecutive parts. Gathering them whenever someone is free does not work. And an out-of-control signal has to reach someone who can stop the process in that shift.

Every part and operation needs its characteristics, tolerances, methods, frequencies and sample sizes entered once. That is the real cost of the project, and it lands on your quality engineers. Plants that already keep control plans in spreadsheets or a PPAP pack are transcribing; plants that keep them in an inspector's head are writing them for the first time. Start with the parts that generate the claims.

No. Software certifies nothing; an auditor looks at what your people actually do. What it removes is the scramble beforehand, because control plans, inspection records, non-conformities, corrective actions and their approvals sit in one place with dates and names attached, so evidence is simply retrieved. If the underlying process is undisciplined, digitalizing it mainly gives you faster access to an accurate picture of that.

Because the two hold different things. The ERP records that a lot passed, was rejected or went to concession, and it needs that to block stock and post scrap. It does not hold the individual measurements, the chart behind them, the photograph of the defect or the 8D. MSF Quality owns that detail and passes the decision to the ERP through an interface that has to be built and mapped for your ERP, including which inspection outcome sets which stock status.

How far back you can go depends on what was captured at the time. Where the lot was scanned at each operation, the record gives you the machine, the operator, the incoming material lot and the inspection values, and the same query finds the other parts that shared them to the extent those were recorded against the operation rather than the order. Where an operation was booked without a scan, the trail thins to the order. How long that detail stays queryable is a retention policy you set.

It works, and it costs you most of the reason to do this. Values entered hours later cannot raise an alert while the parts are still on the machine, and they lose the link between the reading and what the machine was doing when it was taken. You keep the audit trail and lose the control loop. Paper is a reasonable fallback for a station with no terminal, but it does not work as a rollout plan.
